Automatic Forming Machines 自動成型機 / YSM NC-26T
| Capacity |
Wire Diameter |
0.6-3.2 mm |
| Max. Width of Strip |
40 mm |
| Thickness of Strip |
0.3-1.5 mm |
| Hardness of Strip |
80 (CARBON) |
| Length of Feeding |
Unlimited |
| Max. Forming Speed |
200 ppm |
| Tonnage |
Press Capacity |
15 Tons |
| Slide Capacity |
3.0 Tons |
| Stroke |
Press Stroke |
16 mm |
| Slide Stroke |
60 mm |
| Motor Rating |
Feeding |
2.0 HP (1.5 KW) |
| Press |
4.5 HP (3.5 KW) |
| Forming Cam |
3.0 HP (2.2 KW) |
| Rear Processing |
1.5 HP (1.1 KW) |
| Rotation Axis (Optional) |
0.5 HP (0.4 KW) |
| Machine |
Motor Rating |
2.0 HP (1.5 KW) |
| Machine Size (LxBxH) |
2250 x 990 x 1800 mm |
| Weight |
2500 kgs |
Automatic Forming Machines / YSM NC-26T
